Disc Air 230

The DiscAir DA230 is a pneumatic driven spin window solution. It´s fully mechanical so it runs off of any standard compressed shop air source. It provides maximum reliability without the need for any electrical connections. The perfect use for a non-electrical solutions is for applications with less coolant spray and chip debris – the DiscAir DA230

Features

• Requires zero electrical connections.
• Suited to applications having light to medium, intermittent coolant spray.
• Easy Installation and removal for both OEM and retrofit versions. Requires zero modification of the machine window.
• Compatible with the most machine enclosures.
• Reliable and advanced high quality parts for the highest value and long life.
• Easy Installation and removal for both OEM and retrofit versions. Requires zero modification of the machine window. .
• Reliable and advanced high quality parts for the highest value and long life.
• Powered by any standard sources of clean compressed shop air.
• Powered by any standard sources of clean compressed shop air.
• Manifold designed with push fittings. Includes a spare port for air gun drop.
• Set includes 1 meter connection polyurethane (PUR) hose.
• Installs on both glass and polycarbonate.
• Long life, instrument-rated bearing set.
• Balanced, rotating disc window, with chemically strengthened glass.
• Optional DLC* coating for 10X plus resistance to glass wear.
• Mounting plate for easy installation and low life-cycle cost.
• One year limited warranty.
